Generator Excitation System with 100KW To 20MW Output Capacity Fixed Runner Blade and 96% Rated Efficiency for Industrial Power Generation
商品の詳細:
| ブランド名: | Wawushan |
| 証明: | ISO9001 |
| モデル番号: | EX-202503 |
お支払配送条件:
| Minimum Order Quantity: | 1 |
|---|---|
| 価格: | 5000-60000USD |
| パッケージの詳細: | 標準 |
| Delivery Time: | 3 Months |
| Payment Terms: | T/T |
| Supply Ability: | 300 Set Per Unit |
|
詳細情報 |
|||
| 電流範囲: | 0～500A | 定格周波数: | 50Hz |
|---|---|---|---|
| 寸法: | 3Mx3Mx2.5M | 取付タイプ: | パネル取り付けまたはキャビネット取り付け |
| VoltageRange: | 110V～690V | ランナーの刃: | 修理済み |
| レイアウト: | 水平 | 色: | 緑 |
| ハイライト: | 100KW To 20MW Output Capacity Generator Excitation System,Fixed Runner Blade Excitation System,96% Rated Efficiency Synchronous Generator Excitation System |
||
製品の説明
Generator Excitation System
Advanced excitation system with output capacity from 100KW to 20MW, designed for optimal performance and stability in synchronous generators. Features fixed runner blade configuration and exceptional 96% rated efficiency for industrial power generation applications.
Output Capacity
100KW to 20MW
Voltage Range
110V to 690V
Rated Efficiency
96%
Mounting Options
Panel or Cabinet
Product Features
- Fixed runner blade design for consistent performance
- Automatic Voltage Regulator (AVR) control system
- Horizontal layout configuration
- Rated frequency: 50Hz
- Rated current: 5A
- Durable green finish for corrosion resistance
- Advanced excitation technology for stable voltage regulation
- High efficiency operation reducing energy costs
Technical Specifications
| Parameter | Specification |
|---|---|
| Color | Green |
| Voltage Range | 110V to 690V |
| Generator Type | Synchronous Generator |
| Control Type | Automatic Voltage Regulator (AVR) |
| Layout | Horizontal |
| Rated Efficiency | 96% |
| Runner Blade | Fixed |
| Rated Current | 5A |
| Rated Frequency | 50Hz |
| Mounting Type | Panel Mounted or Cabinet Mounted |
Applications
This excitation system is ideal for power generation facilities requiring stable voltage control and reliable performance. Suitable for thermal power plants, hydroelectric stations, industrial manufacturing plants, mining operations, and commercial complexes where continuous, stable power supply is essential.
Customization Options
Model EX-202501 available with custom configurations including current range up to 500A, flexible mounting options, and various power ratings. ISO9001 certified manufacturing with delivery within 3 months.
Support & Services
Comprehensive technical support including installation assistance, commissioning, maintenance services, and operator training. Regular inspection and calibration services available to ensure optimal system performance and longevity.
