詳細情報 |
|||
| ヘッドレンジ: | 50～700メートル | パワーレンジ: | 1400-2200KW |
|---|---|---|---|
| 色: | ブレ | モデル: | XJ02-W-50/1*11 |
| ランナー径: | 1.0 m | 回転: | 1000rpm |
| キーワード: | 高頭水タービン | タイプ: | 油圧タービン |
| ハイライト: | Stainless Steel Runner High Head Water Turbine,Brushless Excitation Control System Hydraulic Turbine,50-700 Meters Head Range Hydroelectric Turbine |
||
製品の説明
High Head Water Turbine with Stainless Steel Runner
The High Head Water Turbine is an advanced hydroelectric power generation solution engineered to efficiently harness energy from water sources with significant vertical drops ranging from 50 to 700 meters. This turbine optimizes performance in high head applications, making it ideal for hydroelectric projects where elevation differences are substantial.
Featuring brushless excitation technology and stainless steel guide vanes, this turbine ensures maximum energy extraction, stable voltage regulation, and reliable power output with minimal maintenance requirements.
Key Features
- Product Name: High Head Water Turbine
- Frequency: 50Hz/60Hz
- Power Range: 1400-2200 KW
- Runner Material: Stainless Steel
- Runner Diameter: 1.0 M
- Operating Temperature: -10°C to 50°C
- Designed for use with bulb generator systems
- Features axial flow generator for efficient energy conversion
- Utilizes axial flow turbine to optimize water flow and power output
Technical Specifications
| Runner Diameter | 1.0 M |
| Runner Material | Stainless Steel |
| Operating Temperature | -10°C To 50°C |
| Color | Blue |
| Phase Type | 3Phase / 1phase |
| Power Range | 1400-2200 KW |
| Water Head | 180 M |
| Control System | Brushless Excitation |
| Frequency | 50Hz / 60Hz |
Applications
The Wawushan High Head Water Turbine (Model T-202501) is ideally suited for applications where significant water head is available, making it perfect for mountainous regions, large dam installations, and hydroelectric power plants requiring reliable continuous power generation.
This turbine excels in remote and off-grid locations, rural electrification projects, and industrial facilities near rivers or reservoirs. Its compatibility with both 50Hz and 60Hz frequencies allows seamless integration with different national grids worldwide.
Customization Options
Wawushan offers comprehensive customization services for the High Head Water Turbine (Model T-202501). Customization options include adjustments to runner diameter, axial flow generators, and bulb generators to optimize performance for specific project requirements.
Support & Services
Our comprehensive support includes installation guidance, maintenance procedures, troubleshooting, and performance optimization. We provide detailed documentation, user manuals, training resources, and regular maintenance services including inspection, cleaning, lubrication, and parts replacement to extend turbine lifespan and minimize downtime.
